key Specifications
Brand
Haier Finish Colour
White
Height (mm)
900 mm
Width (mm)
540 mm
Depth (mm)
600 mm
Model Number
HOR54S5CW1HSH60RSX1
Oven Fuel Type
Electric
Cooktop Type
Solid hotplates
Cooktop Fuel Type
Electric
Rangehood Type
Slideout
Accessories included
1 x Wire rack, 1 x Grill / Bake tray, 1 x Grill insert and 1 x 60mm Mini splashback
warranty
Manufacturer Warranty
2 Years
Use
Not intended or designed for commercial use.
burners
Number of cooktop Burners or Zones
4
functions
Number of Functions
5
Top heating
Conventional
Full grill
Light
other Features
Internal oven light
Features
Oven Features
● Front dial control knobs● Storage drawer is located under oven door
● One-piece inner glass oven door panel
● 1 x 25 Watt halogen oven light
● Removable oven door
● Closed door grilling
● 4 x Levelling feet with 5mm adjustment
● Cooking Zones Power: Left front 1000W - 145mm, Left rear 1500W - 180mm, Right front 2000W - 180mm, Right rear 1000W - 145mm
Rangehood Features
● Stainless steel finish● 2x Halogen lights
● Maximum decibal rating 65 dB
● 400m3h air extraction
● Can be recirculated
electrical Connection
Type of connection
Hardwired
Connection requirements
Needs to be hardwired by a qualified electrician
Maximum current rating
32 A
